| Specification | Details |
|---|---|
| Model | AVA VX10500MC |
| Display Size | 105 Inches |
| Aspect Ratio | 21:9 Ultra-Wide |
| Resolution | 5120 × 2160 |
| Display Area | 2450 × 1034 mm |
| Refresh Rate | 60Hz |
| Display Response Time | 8ms |
| Brightness | 500 cd/m² |
| Contrast Ratio | 4000:1 |
| Viewing Angle | 178° (H/V) |
| Color Depth | 1.07 Billion Colors (10-bit) |
| Color Gamut | 72% NTSC |
| Touch Technology | Infrared Touch, 20 Touch Points |
| Touch Tool | Finger and Passive Infrared Pen |
| Writing Technology | Single Stylus with Dual-Color Writing |
| Touch Accuracy | ±1mm |
| Writing Height | ≤3mm |
| Touch Response Time | ≤5ms |
| Minimum Object Size | 2mm |
| Processor | RK3588, Quad-Core Cortex-A76 + Quad-Core Cortex-A55, 2.4GHz |
| GPU | ARM Mali-G610 MC4 |
| Memory | 8GB / 16GB RAM and 128GB / 256GB ROM |
| Operating System | Android 15 |
| Camera | Built-in 48MP Camera with AI Gesture Mode Switching, Sound-Source Localization and Voice Enhancement |
| Camera Viewing Angle | D: 89° / H: 75° / V: 50° |
| Microphones | 8-Microphone Array, 0–8m Pickup Range, 0°–180° Pickup Angle, Echo Cancellation, Background Noise Suppression and Gain Compensation |
| Audio | 2.1 Channel Audio, 2 × 16W + 20W |
| Wireless | Built-in Dual-Band Wi-Fi 6, 802.11ac/b/g/n/ax, 2.4GHz / 5GHz and Bluetooth 5.2 |
| Touch Compatibility | Windows 10, Windows 8, Windows 7, Windows XP, Android, Linux, macOS and ChromeOS |
| Front Interfaces | 2 × USB 3.0, 1 × HDMI IN, 1 × Touch USB, 1 × USB-C and 1 × Key |
| Onboard Interfaces | 3 × HDMI IN, 1 × HDMI OUT, 1 × DisplayPort IN, 2 × USB 3.0, 1 × USB 2.0, 1 × USB-C IN, 3 × Touch USB, 1 × VGA IN, 1 × Audio IN, 1 × Line OUT, 1 × Coaxial, 1 × RS232, 1 × RJ45 IN and 1 × RJ45 OUT |
| OPS Support | Optional OPS Module Support |
| Power Consumption | Maximum 550W / Standby ≤0.5W |
| Dimensions (W × H × D) | 2507.5 × 1147.8 × 101.1 mm |
| Net / Gross Weight | 94.1 ±1kg / 114.1 ±1kg |
| Mounting | VESA 1000 × 400 mm, M8 × 20mm Screws |
| Included Accessories | Power Cord, Stylus Pen, Wall Mount and Quick Start Guide |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
VX10500MC
The AVA VX10500MC redefines large-format visual communication with its expansive 105-inch ultra-wide interactive display. Designed for executive boardrooms, broadcasting environments, lecture halls, and advanced collaborative spaces, it features a 21:9 aspect ratio with a 5120 × 2160 resolution, 500 cd/m² brightness, and a 4000:1 contrast ratio for clear and immersive presentation.
The panel supports 20-point infrared touch with ±1mm accuracy, ≤5ms touch response, and single-stylus dual-color writing. It integrates a built-in 48MP camera with AI gesture-mode switching, sound-source localization, and voice enhancement, together with an 8-microphone array offering up to 8 meters of pickup distance, echo cancellation, background-noise suppression, and gain compensation. Powered by Android 15 and the RK3588 platform with an 8-core Cortex-A76 and Cortex-A55 processor, the VX10500MC supports up to 16GB RAM, up to 256GB storage, dual-band Wi-Fi 6, Bluetooth 5.2, and optional OPS expansion, making it a premium solution for professional collaboration and immersive communication.
