| Specification | Details |
|---|---|
| Model | AVA VX7500MC Interactive Flat Panel |
| Screen Size | 75 Inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Display Response Time | <5ms |
| Viewing Angle | 178° |
| Brightness | 400 cd/m² |
| Color Gamut | 90% NTSC |
| Display Glass | 3.2mm Anti-Glare Tempered Glass |
| Touch Technology | Infrared Touch, Up to 50 Touch Points |
| Touch Tools | Passive Infrared Pen and Active Infrared Pen |
| Writing Technology | Dual Stylus with Magnetic Docking, Pen Detection and Palm Rejection |
| Touch Accuracy | ±1mm |
| Writing Height | 1mm |
| Touch Response Time | ≤2.5ms |
| Processor | Quad-Core Cortex-A76 + Quad-Core Cortex-A55, Up to 2.4GHz |
| GPU | Mali-G610 MP4 |
| AI Computing Power | 6 TOPS |
| Memory | 16GB RAM / 256GB ROM |
| Operating System | Android 15.0 |
| Camera | Built-in 50MP Camera with Face Detection, WDR and Automatic Backlight Compensation |
| Camera Viewing Angle | HFOV: 92° / VFOV: 63° |
| Microphones | Integrated 8-Microphone Array with Noise Reduction, Voice Gain, Reverberation Suppression and Echo Cancellation |
| Sound Output | 2.2 Channel, 2 × 8W Mid-High + 2 × 20W Bass Speakers |
| Wireless Connectivity | Dual-Band Wi-Fi 6, AP + STA Mode, Bluetooth 5.2 and Built-in NFC Module |
| Network | Gigabit RJ45 IN and RJ45 OUT with USB Type-C / Touch Network Sharing |
| Front Interfaces | HDMI IN, 2 × USB 3.0, USB-C IN and Touch USB |
| Rear Interfaces | 3 × HDMI IN, HDMI OUT, DisplayPort IN, USB 3.0, USB 2.0, USB-C IN, USB-C OUT, RJ45 IN/OUT, Audio IN/OUT, SPDIF, RS232 and Touch USB |
| USB-C Power Delivery | Up to 100W |
| Interactive Features | Pen-Lift Activation, Wireless Screen Sharing, Multi-Screen Output, AI Touch Algorithm, Palm Rejection and NFC Login |
| Power Consumption | Maximum ≤550W / Standby ≤0.5W |
| Dimensions (W × H × D) | 1709.4 × 1038.9 × 85.4 mm |
| VESA Mount | 800 × 400 mm |
| Net Weight | 52.5 kg |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
VX7500MC
Sleek, powerful, and designed for advanced collaboration, the AVA VX7500MC is a 75-inch 4K UHD interactive display featuring an ultra-slim bezel, Zero-Gap assembly, 3.2mm anti-glare tempered glass, and a 90% NTSC color gamut for outstanding visual clarity. Built for modern meeting rooms and educational spaces, it supports up to 50-point infrared touch with palm rejection, dual magnetic stylus docking, and built-in pen detection. The display integrates a 50MP camera with face detection, WDR, and automatic backlight compensation, together with an 8-microphone array for clear audio communication. Powered by Android 15, an 8-core Cortex-A76 and Cortex-A55 processor, 16GB RAM, 256GB storage, Wi-Fi 6, Bluetooth 5.2, NFC, and USB-C PD up to 100W, the VX7500MC delivers a complete solution for seamless interactivity, smart conferencing, and multi-screen collaboration.
