| Specification | Details |
|---|---|
| Model | VX9801MC |
| Display Size | 98 Inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Display Response Time | 8ms |
| Refresh Rate | 60Hz |
| Brightness | 450 cd/m² |
| Contrast Ratio | 1200:1 / 1300:1 / 6000:1 |
| Color Gamut | 72% NTSC |
| Viewing Angle | 178° (H/V) |
| Touch Technology | Infrared Touch, 20 Touch Points on Android and 40 Touch Points on PC |
| Touch Tool | Opaque Objects Including Finger and Stylus Pen |
| Writing Technology | Single Stylus with Dual-Color Writing |
| Touch Accuracy | ±1mm Across More Than 90% of the Touch Area |
| Writing Height | ≤0.99mm |
| Touch Response Time | ≤4.2ms |
| Minimum Object Size | 2mm |
| Camera | Built-in 50MP Camera with Sound-Source Localization, Portrait Tracking, Automatic White Balance and 3D Noise Reduction |
| Camera Viewing Angle | D: 119° / H: 97° / V: 74° |
| Microphones | 8-Microphone Array, 0–8m Pickup Range, 0°–180° Pickup Angle, Echo Cancellation, Background Noise Suppression and Gain Compensation |
| Audio | 2.1 Channel Audio, 2 × 16W + 1 × 20W |
| Operating System | Android 14.0 |
| Processor | 311D2, Quad-Core Cortex-A73 + Quad-Core Cortex-A53, 2.2GHz |
| GPU | ARM Mali-G52 MP8 (8EE) |
| RAM / Storage | 8GB RAM / 128GB ROM |
| Wireless | Built-in Dual-Band Wi-Fi 6, 802.11ac/b/g/n/ax, 2.4GHz / 5GHz and Bluetooth 5.2 |
| Touch Compatibility | Windows 10, Windows 8, Windows 7, Windows XP, Android, Linux, macOS and ChromeOS |
| Front Interfaces | 2 × USB 3.0, 1 × HDMI IN, 1 × Touch USB, 1 × Full-Function USB-C with 65W Power Delivery |
| Onboard Interfaces | 2 × HDMI IN, 1 × HDMI OUT, 1 × DisplayPort IN, 2 × USB 3.0, 1 × USB 2.0, 1 × USB-C, 2 × Touch USB, 1 × VGA IN, 1 × Audio IN, 1 × Line OUT, 1 × Optical OUT, 1 × RS232 and 2 × RJ45 |
| Power Consumption | Maximum 600W / Standby ≤0.5W |
| Dimensions (W × H × D) | 2216.8 × 1331.06 × 104.3 mm |
| Net / Gross Weight | 89.4 ±1kg / 130.55 ±1kg with Pallet |
| Mounting | VESA 1000 × 400 mm, M8 × 20mm Screws |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
VX9801MC
The AVA VX9801MC is a premium 98-inch 4K UHD interactive display designed for large boardrooms, lecture halls, training centers, and smart classrooms. Its expansive screen delivers 450 cd/m² brightness, a 178° viewing angle, and a 72% NTSC color gamut for clear and immersive visual presentation. The panel supports 20 touch points on Android and up to 40 touch points on PC, with ≤4.2ms touch response, ≤0.99mm writing height, and single-stylus dual-color writing for a smooth and precise interactive experience.
Powered by Android 14, an 8-core Cortex-A73 and Cortex-A53 processor, 8GB RAM, and 128GB storage, the VX9801MC delivers reliable performance for modern collaboration and learning environments. It features a built-in 50MP camera with sound-source localization, portrait tracking, automatic white balance, and 3D noise reduction, together with an 8-microphone array offering up to 8 meters of pickup distance, echo cancellation, background-noise suppression, and gain compensation. With built-in dual-band Wi-Fi 6, Bluetooth 5.2, USB-C with 65W power delivery, and 2.1-channel audio, it provides a complete interactive solution for enterprise and education.
