| Specification | Details |
|---|---|
| Model | AVA SX8600 Interactive Flat Panel |
| Screen Size | 86 inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Display Response Time | ≤5ms |
| Viewing Angle | 178° (H/V) |
| Display Glass | 4mm Anti-Glare Tempered Glass |
| Brightness | 400 cd/m² |
| Touch Technology | IR Touch, 40-Point Touch |
| Touch Response Time | ≤5ms |
| Touch Accuracy | ±2mm over 90% of the touch area |
| Writing Technology | Single Stylus Pen with Two-Colour Writing Support |
| Processor | Quad-Core Cortex-A73, 1.5GHz |
| Memory | 8GB RAM / 128GB ROM |
| Operating System | Android 14.0 EDLA |
| Supported Systems | Windows 10, Windows 8, Windows 7, Windows XP, Android, Linux, macOS X and Chrome |
| Audio | 2.0 Channel, 2 × 20W Speakers |
| Wireless Connectivity | Built-in Wi-Fi and Bluetooth 5.4 |
| Front Interfaces | 2 × USB, 1 × HDMI IN, 1 × TOUCH USB and 1 × USB Type-C |
| Onboard Interfaces | RJ45, RS232, Optical Out, Mic In, Line Out, USB 3.0, Touch Out, 2 × HDMI and USB 2.0 |
| Interactive Features | Wireless Screen Mirroring, Split Whiteboard, Dual-Pen Support, Eye Protection, Screen Lock and Touch Lock |
| Power Consumption | Maximum 500W / Standby ≤0.5W |
| Dimensions (W × H × D) | 1952.96 × 1167.21 × 116 mm |
| VESA Mount | 800 × 400 mm |
| Net Weight | 65.4 ± 1 kg |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
SX8600
Designed for large meeting rooms, lecture halls, classrooms, and collaborative spaces, the AVA SX8600 delivers an expansive 86-inch 4K UHD interactive experience with exceptional clarity and responsiveness. Its zero-bonding technology, 4mm anti-glare tempered glass, 400 cd/m² brightness, and 178° viewing angle help reduce reflections and parallax while maintaining clear visuals across large spaces. The 40-point IR touch system, ≤5ms response time, split whiteboard functionality, and dual-pen support enable smooth and efficient multi-user interaction. Powered by Android 14.0 EDLA, a Quad-Core Cortex-A73 processor, 8GB RAM, and 128GB ROM, the SX8600 provides reliable performance for presentations, educational applications, and multimedia content. Built-in Wi-Fi, Bluetooth 5.4, wireless screen mirroring, dual 20W speakers, eye protection, screen lock, and touch lock make it a complete interactive solution for large-scale collaboration.
