| Specification | Details |
|---|---|
| Model | AVA EXT8600MC Interactive Screen with Extended IR Boards |
| Display Size | 86 Inches |
| Resolution | 3840 × 2160 4K UHD |
| Aspect Ratio | 16:9 |
| Display Area | 1895.04 × 1065.96 mm |
| Pixel Pitch | 0.4935 × 0.4935 mm |
| Refresh Rate | 60Hz |
| Display Response Time | 8ms |
| Brightness | 350 cd/m² Typical |
| Contrast Ratio | 1100:1 / 1200:1 / 4000:1 / 5000:1 Typical |
| Color Depth | 1.07 Billion Colors, 10-bit |
| Color Gamut | 72% NTSC |
| Viewing Angle | 178° Horizontal / Vertical |
| Backlight Technology | DLED |
| Display Lifespan | ≥ 30,000 Hours |
| Protective Glass | 4mm Anti-Glare Tempered Glass |
| Bonding Technology | Zero-Bonding Technology with Low-Parallax Writing |
| Brightness Adjustment | Light-Sensor Automatic Brightness Adjustment |
| Touch Technology | Infrared Touch |
| Touch Points | 20-Point Multi-Touch |
| Minimum Object Size | 2mm |
| Touch Tool | Finger or Passive Infrared Pen |
| Touch Response Time | ≤ 10ms |
| Touch Accuracy | ±1mm |
| Writing Height | ≤ 3mm |
| Writing Mode | Single Stylus Pen with Two-Color Writing Support |
| Supported Touch Systems | Windows 10, Windows 8, Windows 7, Windows XP, Android, Linux, Mac OS X and Chrome |
| Processor Chip | GK6760V100 |
| CPU | 8-Core Cortex-A55 |
| Processor Frequency | 1.5GHz |
| GPU | Quad-Core Mali-G52 |
| Memory | 4GB RAM / 32GB Internal Storage |
| Operating System | Android 12.0 |
| OSD Languages | 19 Languages Including English, Arabic, Chinese, Spanish, French, German, Italian and Others |
| Wi-Fi | IEEE 802.11ac / b / g / n / a, Dual-Band 2.4GHz / 5GHz |
| Wi-Fi Operating Distance | 0–10m |
| Bluetooth | Bluetooth 5.0, 2.4GHz, Operating Distance 0–10m |
| Ethernet | 1000Mbps Ethernet Support for Android and OPS |
| Audio System | 2.0-Channel Audio |
| Speaker Power | 2 × 16W |
| Camera | Integrated 13MP Upper-Frame Camera |
| Camera Viewing Angle | 118° |
| Microphones | 8-Microphone Array |
| Microphone Pickup Distance | 0–8m |
| Microphone Pickup Angle | 0°–180° |
| Microphone Features | Echo Cancellation, Background Noise Suppression and Gain Compensation |
| Front USB Ports | USB 3.0 ×2 |
| Front HDMI Input | HDMI Input ×1 |
| Front Touch USB | Touch USB ×1 |
| Front USB Type-C | USB Type-C ×1 with USB Function |
| Memory Card Slot | TF Card Slot ×1 |
| Front Controls | Six Front-Panel Control Keys |
| Onboard USB Ports | USB-A 2.0 for Android ×1 and USB-A 2.0 Public ×1 |
| Onboard HDMI Ports | HDMI Input with ARC ×1 and Standard HDMI Input ×1 |
| Onboard Touch Port | Touch Port ×1 |
| Control Port | RS232 ×1 |
| Audio Ports | Line Out ×1, Coaxial Audio ×1 and Microphone Input ×1 |
| Network Port | LAN Input ×1 |
| Wireless Screen Mirroring | Supported |
| Network Sharing | Supported |
| Whiteboard Features | Split Whiteboard, Parallel Tasks and Wider Interactive Workspace |
| Multi-User Support | Supported |
| Dual-Pen Support | Supports Simultaneous Pens with Different Colors |
| Intelligent Wake-Up | Supports HDMI, VGA, RS232 and Network Signal Wake-Up from Standby |
| Additional Features | 4K UI, 4K Full-Channel Screen Recording, Hover-Ball Menu, Eye Protection, Screen Lock and Touch Lock |
| Power Requirements | Rated 100–240V AC, Maximum 90–264V AC, 50/60Hz |
| Maximum Power Consumption | 480W |
| Standby Power | ≤ 0.5W |
| Dimensions Without Auxiliary Boards | 1976.25 × 1164.66 × 83.07 mm |
| Dimensions With Auxiliary Boards | 4200 × 1164.66 × 100.45 mm |
| Package Dimensions | 2120 × 220 × 1325 mm |
| Wall-Mount Screw | M8 × 60 mm Expanding Screw |
| Main Screen Net Weight | 64 ±1 kg |
| Auxiliary Boards Net Weight | 18.1 ±1 kg |
| Main Screen Gross Weight | 79.5 ±1 kg |
| Auxiliary Boards Gross Weight | 25.1 ±1 kg |
| Optional OPS Module | 195 × 180 × 30 mm or 195 × 180 × 42 mm |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10%–90% RH |
| Storage Temperature | −20°C to 60°C |
| Storage Humidity | 10%–90% RH |
| Maximum Altitude | Below 5000m |
| Included Accessories | Power Cord ×1, Stylus Pen ×1, Wall Mount ×1 and Quick Start Guide ×1 |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
EXT8600MC
The AVA EXT8600MC is an 86-inch 4K UHD interactive screen designed with extended infrared boards to create a wider and more engaging collaboration environment. Its zero-bonding design, 4mm anti-glare tempered glass, automatic brightness adjustment, and precise 20-point infrared touch technology provide a natural writing experience with low parallax, a response time of no more than 10ms, and touch accuracy of ±1mm. The extended side boards support multi-user interaction, dual-color pen input, split whiteboarding, and parallel tasks, making the display ideal for modern classrooms, lecture halls, training centers, and collaborative workspaces.
Powered by the GK6760V100 processor with an eight-core Cortex-A55 CPU, Android 12.0, 4GB RAM, and 32GB of internal storage, the EXT8600MC delivers reliable performance for interactive applications, wireless screen mirroring, network sharing, and 4K content. Dual-band Wi-Fi, Bluetooth 5.0, Gigabit Ethernet support for Android and OPS, a 13MP upper-frame camera, an eight-microphone array with an operating range of up to 8 meters, and integrated 2 × 16W speakers support clear communication and multimedia use. Intelligent wake-up, eye protection, screen lock, touch lock, and optional OPS integration further enhance its suitability for education, presentations, video conferencing, and professional collaboration.
