EP5500G

Designed for large retail spaces, shopping malls, corporate reception areas, hospitality venues, exhibitions, and professional visual communication, the AVA EP6500G delivers an impressive 65-inch high-resolution floor-standing digital signage solution. Powered by Android 12.0, 2GB RAM, and 32GB storage, it provides reliable performance for displaying images, videos, presentations, web pages, office files, promotional content, and Android applications. Its WLED display offers a 3840 × 1920 resolution, 310 ± 10 cd/m² brightness, a 1200:1 contrast ratio, and a wide 178° horizontal and vertical viewing angle for clear and consistent content visibility. With intelligent content scheduling, timed power control, remote monitoring, local USB upgrades, USB 2.0, USB 3.0, HDMI input, LAN connectivity, TF card support, and Line-Out, the EP6500G is an efficient solution for digital advertising, large-format information displays, wayfinding, and automated content management.

Specification Details
Model AVA EP5500G Floor-Standing Digital Signage
Display Size 55 Inches
Backlight WLED
Display Area 1209 × 680 mm
Resolution 3840 × 2160 Pixels (4K UHD)
Brightness 310 ± 10 cd/m² (Typical)
Contrast Ratio 1200:1 (Typical)
Response Time 8ms (Typical)
Refresh Rate 60Hz
Viewing Angle 178° (H/V)
Panel Lifetime 30,000 Hours Minimum
Operating System Android 12.0
Memory / Storage 2GB / 32GB
Touch System Non-touch
Power Requirements AC 100–240V, 50/60Hz
Power Consumption ≤110W Maximum / <0.5W Standby
Connectivity USB 2.0 × 1, USB 3.0 × 1, HDMI Input × 1,
LAN × 1, TF Card × 1 and Line-Out × 1
Maximum Operating Time 7 Days × 18 Hours
Operating Temperature 0°C to 40°C
Storage Temperature −10°C to 60°C
Storage Humidity 10%–90% RH, Non-Condensing
Operating Humidity 20%–85% RH, Non-Condensing
Installation Type Floor-Standing
Shell Material Aluminum Profile and Sheet Metal
Color Silver/Black Aluminum Profile with Black Sheet Metal
Dimensions 1880 × 757 × 83.8 mm
Packaging Dimensions 1915 × 195 × 847 mm
Net Weight 50 ± 1 kg
Gross Weight 55 ± 1 kg
