| Specification | Details |
|---|---|
| Model | AVA DX6501TG Wall-Mounted Digital Signage |
| Display Size | 65 Inches |
| Panel Grade | A Grade |
| Backlight | LED |
| Resolution | 3840 × 2160 Pixels (4K UHD) |
| Brightness | 300 ± 10 cd/m² (Typical) |
| Contrast Ratio | 1100:1 / 1200:1 / 4000:1 / 5000:1 (Typical) |
| Refresh Rate | 60Hz |
| Viewing Angle | 178° (H/V) |
| Panel Lifetime | 50,000 Hours Minimum |
| Display Colors | 16.7 Million Colors, 99% sRGB |
| Processor | 8-Core A55 |
| GPU | G52 × 4 |
| Memory | 2GB RAM / 32GB Storage |
| Operating System | Android 12.0 |
| Touch Technology | 10-Point Capacitive Touch |
| Audio | 2 × 5W Speakers |
| Power Consumption | ≤220W Maximum / <0.5W Standby |
| Connectivity | DC 12V Input × 1, USB 2.0 × 1, USB 3.0 × 1, RJ45 Ethernet 100M × 1, HDMI IN 2.0 × 1, TF Card × 1 and Line-Out × 1 |
| VESA Mount | 400 × 400 mm, 4 × M6 Screws |
| Dimensions | 1481 × 856 × 66.6 mm — Estimated in Datasheet |
| Net Weight | TBD — Not Specified in the Datasheet |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
DX6501TG
Designed for large retail spaces, corporate environments, hospitality venues, exhibition areas, and professional visual communication, the AVA DX6501TG delivers an impressive 65-inch 4K UHD touch-enabled digital signage solution. Powered by an 8-Core A55 processor, Android 12.0, 2GB RAM, and 32GB storage, it provides reliable performance for displaying images, videos, presentations, web pages, office files, and Android applications. Its LED display offers a sharp 3840 × 2160 resolution, 300 ± 10 cd/m² brightness, typical contrast options of 1100:1, 1200:1, 4000:1, or 5000:1, and a wide 178° viewing angle for clear and consistent content visibility. With 10-point capacitive touch, intelligent content scheduling, horizontal and vertical display support, remote monitoring, USB 2.0, USB 3.0, HDMI 2.0, RJ45 Ethernet, TF card support, Line-Out, and built-in dual 5W speakers, the DX6501TG is an efficient solution for interactive advertising, large-format information displays, and automated content management.
