Specification |
Details |
|---|---|
| Model | AVA DX5502 Wall-Mounted Digital Signage |
| Display Size | 55 Inches |
| Panel Grade | A Grade |
| Backlight | LED |
| Resolution | 3840 × 2160 Pixels (4K UHD) |
| Brightness | 500 cd/m² (Typical) |
| Contrast Ratio | 1200:1 |
| Pixel Pitch | 0.49005 × 0.49005 mm (H × V) |
| Refresh Rate | 60Hz |
| Viewing Angle | 178° (H/V) |
| Panel Lifetime | 50,000 Hours Minimum |
| Display Colors | 1.07 Billion Colors (8-bit + Hi-FRC) |
| Chipset | MT9679 |
| Processor | Quad-Core Cortex-A73 |
| GPU | Mali G52-MC1 |
| Memory | 4GB RAM / 32GB Storage |
| Operating System | Android 14.0 |
| Audio | 2 × 5W Speakers |
| Power Consumption | ≤120W Maximum / <0.5W Standby |
| Power Input | AC 100–240V, 50/60Hz |
| Connectivity |
Type-C × 1, USB 3.0-A × 2, HDMI IN 2.1 × 3, RJ45 × 1, SIM × 1, DC Input × 1 and Line-Out × 1 |
| Display Orientation | Horizontal and Vertical |
| VESA Mount | 400 × 400 mm |
| Dimensions | 1237.95 × 710.05 × 28.5 mm |
| Net Weight | 16.95 ± 1 kg |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
DX5502
Designed for retail spaces, corporate environments, hospitality venues, exhibition areas, and professional visual communication, the AVA DX5502 delivers a powerful 55-inch 4K UHD digital signage solution. Powered by a Quad-Core Cortex-A73 processor, Android 14.0, 4GB RAM, and 32GB storage, it provides smooth and reliable performance for displaying images, videos, presentations, web pages, office files, and Android applications. Its LED display offers a sharp 3840 × 2160 resolution, 500 cd/m² brightness, a 1200:1 contrast ratio, and a wide 178° horizontal and vertical viewing angle for clear and consistent content visibility. With intelligent content scheduling, horizontal and vertical display support, remote monitoring, USB playback, three HDMI 2.1 inputs, USB Type-C, RJ45 Ethernet, SIM support, Line-Out, and built-in dual 5W speakers, the DX5502 is an efficient solution for digital advertising, large-format information displays, and automated content management.
