| Specification | Details |
|---|---|
| Model | AVA EP4300TCG Floor-standing Capacitive Digital Signage |
| Screen Size | 43 inches |
| Backlight Type | WLED |
| Display Area | 940.8 × 529.3 mm |
| Resolution | 1920 × 1080 pixels |
| Operating System | Android 12 |
| Memory | 2GB RAM / 32GB Storage |
| Touch Technology | 10-Point Capacitive Touch |
| Brightness | 300 ± 10 cd/m² |
| Contrast Ratio | 1200:1 |
| Response Time | 8ms |
| Refresh Rate | 60Hz |
| Viewing Angle | 178° (H/V) |
| Panel Lifetime | 30,000 hours minimum |
| Connectivity | USB 2.0, USB 3.0, TF Card, HDMI Input, LAN and Line-Out |
| Power Requirements | 100–240V, 50–60Hz |
| Maximum Power | ≤90W |
| Standby Power | <0.5W |
| Operating Hours | Up to 18 hours per day, 7 days per week |
| Product Dimensions | 1780.5 × 602.4 × 83.8 mm |
| Packaging Dimensions | 1815 × 180 × 692 mm |
| Net Weight | 38 ± 1 kg |
| Gross Weight | 42 ± 1 kg |
| Shell Material | Aluminum Profile and Sheet Metal |
| Display Features |
Built-in Content Publishing System, Scheduled Playback, USB Content Import, Remote Monitoring and Horizontal/Vertical Display Support |
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
Home Automation
GM – Master Gateways
GR – Repeater Gateways
TPS
TPM
TPL
TPX
SMP – Motion Presence Sensor
SIR – Infrared Sensor
SDW – Door Window Sensor
SHT – Humidity Temp Sensor
SSM – Smoke Sensor
SGA – Gas Sensor
SWL – Water Leakage Sensor
TS – Touch Switches
CS – Curtain Switches
HS – High Current Switches
DL – Door Lock
IC – Intercom
EP4300TCG
Designed for retail stores, showrooms, reception areas, exhibitions, and public information spaces, the AVA EP4300TCG delivers a compact and responsive 43-inch floor-standing digital signage experience. Powered by Android 12 with 2GB RAM and 32GB storage, it supports the playback of images, videos, presentations, web pages, APK applications, office files, and other multimedia content. Its 10-point capacitive touch system provides smooth and accurate interaction, while the 1920 × 1080 Full HD display, 300 ± 10 cd/m² brightness, 1200:1 contrast ratio, and 178° viewing angle ensure clear and consistent content visibility. With HDMI, USB 2.0, USB 3.0, TF card, LAN, and Line-Out connectivity, along with scheduled playback, USB content import, remote monitoring, and horizontal or vertical display support, the EP4300TCG offers a practical and professional solution for interactive advertising, digital information, and customer engagement.
